8 - Technical specifications
98
Filters and Nozzles
*depending on selected nozzles
**not with PrimeFlow system
Temperature and Pressure Ranges
Spray Liquid System
Power Consumption
Technical Residue
Residue in the dilutable volume is mentioned in the table below.
The non-dilutable volume varies depending on the boom width and installed options in the fluid system.
Airborne Noise Emission
Airborne noise emission from operating the sprayer relates to the two defined operator positions (in the tractor cab or
operating the chemical incorporator/filling device/TurboFiller). Reference measurements indicate only in the latter case
(operating the chemical filling device) a contribution from the sprayer of additionally 4 dB(A).
Filter
Mesh Gauze width Color To p -mo un te d Self-cleaning In-line** Tank strainer Nozzle
18 1.00 mm White - - - Yes -
300.58 mmGreenYes----
50 0.30 mm Blue Yes, standard - Yes* - Yes*
80 0.18 mm Red Yes Yes Yes* - Yes*
100 0.15 mm Yellow - - Yes* - Yes*
Operating temperature range 2 - 40 °C
Operating pressure for the safety valve 15 bar
Max. pressure on the pressure manifold 20 bar
Max. pressure on the suction manifold 1.5 bar
Sprayer tank volume Output Output
1200 litres 115 hp 86 kW
1500 litres 132 hp 99 kW
1800 litres 152 hp 114 kW
Sprayer combination Dilutable volume for tank and fluid system
Main tank: 1000 litres
Boom width: 12 meters
16 litres
