Monitoring and troubleshooting
How to monitor the RF inputs
RF default parameters
Each XOS comes with the RF parameters used by Warner Media.
Each RF port is used and corresponds to the following transponder:
RF1 = WM-20 - Satellite Intelsat Galaxy 30
RF2 = WM-21 - Satellite Intelsat Galaxy 30
RF3 = WM-18 - Satellite Intelsat Galaxy 33
RF4 = WM-19 - Satellite Intelsat Galaxy 33
The Local Oscillator frequency values are:
Port 1 to 4: 5.15 GHz
Each tuner has its own parameters:
Tuner 1
WM-20
Tuner 2
WM-21
Tuner 3
WM-18
Tuner 4
WM-19
Symbol Rate 34.286Msps 34.286Msps 34.286Msps 34.286Msps
Carrier Frequency 4100 4120 4060 4080
Polarization V H V H
Spectral Inversion Auto Auto Auto Auto
Modulation 16 APSK 16 APSK 16 APSK 16 APSK
FEC 2/3 2/3 2/3 2/3
Pilots Off Off Off Off
Pls Code 0 0 0 0
Roll Off (%) 5 5 5 5
