Harris Constellation - Page 60

Constellation® January 2006
4-6 Technical Specifications
7 to 8 8 DS1 NP 27.5 -81.5 -80.0 109.0 107.5
NP/SD 27.5 -81.5 -80.0 109.0 107.5
HS
d
27.1 -80.6 -79.1 107.7 106.2
HS/SD 27.1 -81.5 -80.0 108.6 107.1
ST/SD 27.1 -81.5 -80.0 108.6 107.1
FD 27.5 -81.5 -80.0 109.0 107.5
FD/SD 27.5 -81.5 -80.0 109.0 107.5
16 DS1 NP 26.5 -75.0 -73.5 101.5 100.0
NP/SD 26.5 -75.0 -73.5 101.5 100.0
HS
d
26.1 -74.1 -72.6 100.2 98.7
HS/SD 26.1 -75.0 -73.5 101.1 99.6
ST/SD 26.1 -75.0 -73.5 101.1 99.6
FD 26.5 -75.0 -73.5 101.5 100.0
FD/SD 26.5 -75.0 -73.5 101.5 100.0
28 DS1/DS3 NP 27.0 -75.0 -73.5 102.0 100.5
NP/SD 27.0 -75.0 -73.5 102.0 100.5
HS
d
26.6 -74.1 -72.6 100.7 99.2
HS/SD 26.6 -75.0 -73.5 101.6 100.1
ST/SD 26.6 -75.0 -73.5 101.6 100.1
FD 27.0 -75.0 -73.5 102.0 100.5
FD/SD 27.0 -75.0 -73.5 102.0 100.5
16 DS1
High Gain
NP 27.0 -77.0 -76.0 104.0 103.0
NP/SD 27.0 -77.0 -76.0 104.0 103.0
HS
d
26.6 -76.1 -75.1 102.7 101.7
HS/SD 26.6 -77.0 -76.0 103.6 102.6
ST/SD 26.6 -77.0 -76.0 103.6 102.6
FD 27.0 -77.0 -76.0 104.0 103.0
FD/SD 27.0 -77.0 -76.0 104.0 103.0
28 DS1/DS3
High Gain
NP 28.0 -77.5 -76.5 105.5 104.5
NP/SD 28.0 -77.5 -76.5 105.5 104.5
HS
d
27.6 -76.6 -75.6 104.2 103.2
HS/SD 27.6 -77.5 -76.5 105.1 104.1
ST/SD 27.6 -77.5 -76.5 105.1 104.1
FD 28.0 -77.5 -76.5 105.5 104.5
FD/SD 28.0 -77.5 -76.5 105.5 104.5
Table 4-3: RF performance specifications (Continued)
Receive
Threshold
System Gain
a
Band (GHz) Capacity Config-
uration
b
Tx Pwr
Output
(dBm)
10
-3
BER
(dBm)
10
-6
BER
(dBm)
10
-3
BER
(dB)
10
-6
BER
(dB)
