Harris Corporation Constellation®
RF Performance Specifications 4-5
TECHNICAL
SPECIFICATIONS
5.9 to 6.9
c
155 Mbps
opt./elec.,
3xDS3
Standard Gain
NP 29.0 -72.5 -71.0 101.5 100.0
NP/SD 29.0 -72.5 -71.0 101.5 100.0
HS
d
28.6 -71.5 -70.0 100.1 98.6
HS/SD 28.6 -72.5 -71.0 101.1 99.6
ST/SD 28.6 -72.5 -71.0 101.1 99.6
FD 29.0 -72.5 -71.0 101.5 100.0
FD/SD 29.0 -72.5 -71.0 101.5 100.0
155 Mbps
opt./elec.,
3xDS3 High
Gain
NP 31.5 -72.5 -71.0 104.0 102.5
NP/SD 31.5 -72.5 -71.0 104.0 102.5
HS
d
31.1 -71.5 -70.0 102.6 101.1
HS/SD 31.1 -72.5 -71.0 103.6 102.1
ST/SD 31.1 -72.5 -71.0 103.6 102.1
FD 31.5 -72.5 -71.0 104.0 102.5
FD/SD 31.5 -72.5 -71.0 104.0 102.5
4xDS3
Standard Gain
NP 29.0 -69.0 -68.0 98.0 97.0
NP/SD 29.0 -69.0 -68.0 98.0 97.0
HS
d
28.6 -68.0 -67.0 96.6 95.6
HS/SD 28.6 -69.0 -68.0 97.6 96.6
ST/SD 28.6 -69.0 -68.0 97.6 96.6
FD 29.0 -69.0 -69.0 98.0 97.0
FD/SD 29.0 -69.0 -68.0 98.0 97.0
4xDS3
High Gain
NP 31.0 -69.0 -68.0 100.0 99.0
NP/SD 31.0 -69.0 -68.0 100.0 99.0
HS
d
30.6 -68.0 -67.0 98.6 97.6
HS/SD 30.6 -69.0 -68.0 99.6 98.6
ST/SD 30.6 -69.0 -68.0 99.6 98.6
FD 31.0 -69.0 -68.0 100.0 99.0
FD/SD 31.0 -69.0 -68.0 100.0 99.0
Table 4-3: RF performance specifications (Continued)
Receive
Threshold
System Gain
a
Band (GHz) Capacity Config-
uration
b
Tx Pwr
Output
(dBm)
10
-3
BER
(dBm)
10
-6
BER
(dBm)
10
-3
BER
(dB)
10
-6
BER
(dB)
