HMX6801+B2/C2 and HMX6801+B4/C4 Installation and Operation Manual 41
Chapter 3: Operation
Table 3-9. Parameter Options—HMX6801+B2/C2 Modules
Bank, Rotary
Switch
Parameter
Name
Function Options
0, 1 SDI IP Video Std
Set
Selects the SDI input video signal
standard
• Auto
• 1035I30
• 1035I29.97
• 1080I25 (295M)
• 1080I30
• 1080I29.97
• 1080I25
• 1080P30
• 1080P29.97
• 1080P25
• 1080P24
• 1080P23.98
• 720P60
• 720P59.94
• 720P50
• SD-525
• SD-625
0, 2 Y CRC Err Cnt
Clear
Clears the luminance CRC error
counter
• No
•Yes
0, 3 C CRC Err Cnt
Clear
Clears the chrominance CRC error
counter
• No
•Yes
0, 4 EDH Err Clr Clears the EDH error counter
• No
•Yes
0, 5 DARS Input Type Selects the type of DARS input
(balanced / unbalanced)
• Balanced
• Unbalanced
0, 6 ADS Clean Cleans the Ancillary Data Space
prior to audio embedding
• No
•Yes
