42 HMX6801+B2/C2 and HMX6801+B4/C4 Installation and Operation Manual
Chapter 3: Operation
0, 7 Embed Group
Select
1
Selects the audio groups to be
embedded
• 1 & 2
•1 & 3
•1 & 4
•2 & 3
•2 & 4
•3 & 4
0, 8 Embedder 1
Mode
Selects the embedding mode for the
first embedder
•Off
• Append
• OverWrt
• Auto
0, 9 Embedder 2
Mode
Selects the embedding mode for the
second embedder
• Off
• Append
• OverWrt
• Auto
0, A Input Ch1A
Delay
Adjusts delay for input channel
AES 1A
0.0 to 1320.0 msec
0, B Input Ch1B Delay Adjusts delay for input channel
AES 1B
0.0 to 1320.0 msec
0, C Input Ch2A
Delay
Adjusts delay for input channel
AES 2A
0.0 to 1320.0 msec
0, D Input Ch2B Delay Adjusts delay for input channel
AES 2B
0.0 to 1320.0 msec
0, E V-Bit Mute
Enable
Enables audio channel muting upon
detection of an incoming set V-bit
• No
•Yes
0, F Factory Recall Recalls the factory settings
• Off
•On
Table 3-9. Parameter Options—HMX6801+B2/C2 Modules(Continued)
Bank, Rotary
Switch
Parameter
Name
Function Options
