HMX6801+B2/C2 and HMX6801+B4/C4 Installation and Operation Manual 43
Chapter 3: Operation
1, 1 Out 01 Source
Select
Selects the source for output
channel 01
• AES 1A
• AES 1B
• AES 2A
• AES 2B
•AES 1 Sum
•AES 2 Sum
• TstTone 1
• TstTone 2
• TstTone 3
•TstTone 4
1, 2 Out 02 Source
Select
Selects the source for output
channel 02
• AES 1A
• AES 1B
• AES 2A
• AES 2B
•AES 1 Sum
•AES 2 Sum
• TstTone 1
• TstTone 2
• TstTone 3
•TstTone 4
1, 3 Out 03 Source
Select
Selects the source for output
channel 03
• AES 1A
• AES 1B
• AES 2A
• AES 2B
•AES 1 Sum
•AES 2 Sum
• TstTone 1
• TstTone 2
• TstTone 3
•TstTone 4
Table 3-9. Parameter Options—HMX6801+B2/C2 Modules(Continued)
Bank, Rotary
Switch
Parameter
Name
Function Options
