44 HMX6801+B2/C2 and HMX6801+B4/C4 Installation and Operation Manual

Chapter 3: Operation

1, 4 Out 04 Source

Select

Selects the source for output

channel 04

• AES 1A

• AES 1B

• AES 2A

• AES 2B

•AES 1 Sum

•AES 2 Sum

• TstTone 1

• TstTone 2

• TstTone 3

•TstTone 4

1, 5 Out 05 Source

Select

Selects the source for output

channel 05

• AES 1A

• AES 1B

• AES 2A

• AES 2B

•AES 1 Sum

•AES 2 Sum

• TstTone 1

• TstTone 2

• TstTone 3

•TstTone 4

1, 6 Out 06 Source

Select

Selects the source for output

channel 06

• AES 1A

• AES 1B

• AES 2A

• AES 2B

•AES 1 Sum

•AES 2 Sum

• TstTone 1

• TstTone 2

• TstTone 3

•TstTone 4

Table 3-9. Parameter Options—HMX6801+B2/C2 Modules(Continued)

Bank, Rotary

Switch

Parameter

Name

Function Options
