46 HMX6801+B2/C2 and HMX6801+B4/C4 Installation and Operation Manual
Chapter 3: Operation
2, 4 to
2, B
Output Ch01
Gain
to
Output Ch08
Gain
Adjusts gain for output channels 01
to 08
-18.0 to 18.0 dB (0.0)
2,C to
3, 4
Output Ch01
Invert
to
Output Ch08
Invert
Inverts control for output channels
01 to 08
• No
•Yes
3,5 to
3, C
Output Ch01
Mute
to
Output Ch08
Mute
Enables muting for output channels
01 to 08
• Off
•On
3, D Out 01-02 Dithr
Mode
Enables dithering for output
channel pair 01-02
• None
•On
3, E Out 03-04 Dithr
Mode
Enables dithering for output
channel pair 03-04
• None
•On
3, F Out 05-06 Dithr
Mode
Enables dithering for output
channel pair 05-06
• None
•On
4, 1 Out 07-08 Dithr
Mode
Enables dithering for output
channel pair 07-08
• None
•On
4, 2 Out Ch01-02
Word Len
Selects the word length for output
audio channel pair 01-02
• 24 bits
• 20 bits
• 16 bits
4, 3 Out Ch03-04
Word Len
Selects the word length for output
audio channel pair 03-04
• 24 bits
• 20 bits
• 16 bits
4, 4 Out Ch05-06
Word Len
Selects the word length for output
audio channel pair 05-06
• 24 bits
• 20 bits
• 16 bits
Table 3-9. Parameter Options—HMX6801+B2/C2 Modules(Continued)
Bank, Rotary
Switch
Parameter
Name
Function Options
