HMX6801+B2/C2 and HMX6801+B4/C4 Installation and Operation Manual 47
Chapter 3: Operation
4, 5 Out Ch07-08
Word Len
Selects the word length for output
audio channel pair 07-08
• 24 bits
• 20 bits
• 16 bits
4, 6 Fade Rate Controls the rate of fading when
channels are swapped or muted
0.0 to 10.0 sec (1.0)
1 When group numbers are assigned to the embedders, Embedder1 is always assigned a lower group
number: i.e. if Embedder Group Selection (EmbGrpSel) is set to 2&4, Embedder 1 is assigned to
group 2 and Embedder 2 is assigned to group 4.
2 Use Non-PCM channel format when passing compressed audio such as Dolby-E.
Table 3-9. Parameter Options—HMX6801+B2/C2 Modules(Continued)
Bank, Rotary
Switch
Parameter
Name
Function Options
