56 HMX6801+B2/C2 and HMX6801+B4/C4 Installation and Operation Manual
Chapter 3: Operation
1, B Out 08 Source
Select
Selects the source for output
channel 08
• AES 1A
• AES 1B
• AES 2A
• AES 2B
• AES 3A
• AES 3B
• AES 4A
• AES 4B
•AES 1 Sum
•AES 2 Sum
•AES 3 Sum
•AES 4 Sum
• TstTone 1
• TstTone 2
• TstTone 3
•TstTone 4
1, C
to
2, 4
Output Ch01
Format
to
Output Ch08
Format
Selects the AES format for output
channels 01 to 08
•PCM
•Non-PCM
2
• Auto
2, 5
to
2, C
Output Ch01
Gain
to
Output Ch08
Gain
Adjusts gain for output channels 01
to 08
-18.0 to 18.0 dB (0.0)
2, D
to
3, 5
Output Ch01
Invert
to
Output Ch08
Invert
Inverts control for output channels
01 to 08
• No
•Yes
3, 6
to
3, D
Output Ch01
Mute
to
Output Ch08
Mute
Enables muting for output channels
01 to 08
• Off
•On
Table 3-11. Parameter Options - HMX6801+B4/C4 (Continued)
Bank, Rotary
Switch
Parameter
Name
Function Options
