HMX6801+B2/C2 and HMX6801+B4/C4 Installation and Operation Manual 57
Chapter 3: Operation
3, E Out 01-02 Dithr
Mode
Enables dithering for output
channel pair 01-02
• None
•On
3, F Out 03-04 Dithr
Mode
Enables dithering for output
channel pair 03-04
• None
•On
4, 1 Out 05-06 Dithr
Mode
Enables dithering for output
channel pair 05-06
• None
•On
4, 2 Out 07-08 Dithr
Mode
Enables dithering for output
channel pair 07-08
• None
•On
4, 3 Out Ch01-02
Word Len
Selects the word length for output
audio channel pair 01-02
• 24 bits
• 20 bits
• 16 bits
4, 4 Out Ch03-04
Word Len
Selects the word length for output
audio channel pair 03-04
• 24 bits
• 20 bits
• 16 bits
4, 5 Out Ch05-06
Word Len
Selects the word length for output
audio channel pair 05-06
• 24 bits
• 20 bits
• 16 bits
4, 6 Out Ch07-08
Word Len
Selects the word length for output
audio channel pair 07-08
• 24 bits
• 20 bits
• 16 bits
4, 7 Fade Rate Controls the rate of fading when
channels are swapped or muted
0.0 to 10.0 sec (1.0)
1 When group numbers are assigned to the embedders, Embedder1 is always assigned a lower group
number: i.e. if Embedder Group Selection (EmbGrpSel) is set to 2&4, Embedder 1 is assigned to group
2 and Embedder 2 is assigned to group 4.
2 Use Non-PCM channel format when passing compressed audio such as Dolby-E.
Table 3-11. Parameter Options - HMX6801+B4/C4 (Continued)
Bank, Rotary
Switch
Parameter
Name
Function Options
