Instructions for installation and use p. 47/48
16. Technical data
Ambient conditions
Storage temperature: -25 °C to +70 °C
Ambient temperature: -10 °C to +40 °C
Relative humidity: max. 95 %
Sauna control unit
Dimensions: 307 x 175 x 57 mm
Switched voltage / three-phase 3N: 400 V AC
Frequency: 50 Hz
Contact rating/heater: 3 x 3.5 kW
Switched current per phase/heater: 16 A
Contact rating/additional output (dimmable)* 500 W
Contact rating/additional output (switchable)* 3.5 W
Switched current/additional output: 16 A
Status output: 24 V/200 mA
Rated voltage: 230 V
Protection type (protected against jets of water): IPX4
Connection to the mains supply as xed wiring (xed connection)
Light
Contact rating: 100 W
Fuse: 1A T
Fan
Contact rating: 100 W
Fuse: 1A T
Setting ranges
Temperature: 30 °C to 110 °C
* The additional output has no excess temperature fuse.. For this reason, only
intrinsically safe devices should be operated using the additional output.
