CFV 100C
User Manual
CONTENTS
31
A
B
C
Remote Control of EL Camera
Connect the CFV and the socket at the
bottom right of the Winder EL camera (C)
using the exposure cable EL (A).
The 2.5mm connector shall be connected
from the ELX socket on the CFV (B).
When the camera is connected via USB to a
computer running Phocus, users can release
the camera from the computer. Refer to the
Phocus User Guide for more details.
