1.6 MOUNTING THE LENS SHADE
When mounting the lens shade normally (Figure A), align the orange mark on the lens shade
and the mark on the front of the lens. Rotate the lens shade clockwise to secure it.
When mounting the lens shade in reverse (Figure B), align the white mark on the lens shade
and the mark on the front of the lens. Rotate the lens shade clockwise to secure it.
Mount the lens shade in reverse for additional protection during transport and storage.
A B
