Hasselblad X2D 100C - Attaching the Shoulder Strap

X2D 100C
User Manual
CONTENTS
21
1.8 ATTACHING THE SHOULDER STRAP
Attach the buckle of the shoulder strap to the strap lug on side of the camera body. Press
the top part of the buckle (1) as shown in the figure below. Slide the buckle down to secure
it to the strap lug (2).
To remove the buckle, pinch both sides of the buckle, pull out the metal piece slightly, and
lift the buckle.
1
2
2
1
