Hawking HW12ACM User Manual

26
4-1-3. Wireless Monitor
Wireless Monitor is a tool built into the access point to scan and monitor the
surrounding wireless environment. Select a frequency and click “Scan” to display a list of all SSIDs within
range along with relevant details for each SSID.
Wireless Monitor
Site Survey
Select which frequency (or both) to scan, and click “Scan” to
begin.
Channel Survey Result
After a scan is complete, click “Export” to save the results to
local storage.
Site Survey Results
Ch
Displays the channel number used by the specified SSID.
SSID
Displays the SSID identified by the scan.
MAC Address
Displays the MAC address of the wireless router/access point
for the specified SSID.
Security
Displays the authentication/encryption type of the specified
SSID.
Signal (%)
Displays the current signal strength of the SSID.
