4-2-3. VLAN

The “VLAN” (Virtual Local Area Network) enables you to configure VLAN

settings. A VLAN is a local area network which maps workstations virtually instead of physically and allows

you to group together or isolate users from each other. VLAN IDs 1 – 4094 are supported.

VLAN IDs in the range 1 – 4094 are supported.

VLAN Interface

Wired LAN Port/Wireless

Identifies LAN port 1 and wireless SSIDs (2.4GHz or 5GHz).

VLAN Mode

Select “Tagged Port” or “Untagged Port” for LAN interface.

VLAN ID

Set a VLAN ID for specified interface, if “Untagged Port” is

selected.

Management VLAN

VLAN ID

Specify the VLAN ID of the management VLAN. Only the hosts

belonging to the same VLAN can manage the device.
