4-2. Network Settings
Screenshots displayed are examples. The information shown on your screen will vary
depending on your configuration.
4-2-1. LAN-Side IP Address
The “LAN-side IP address” page allows you to configure your access point on
your Local Area Network (LAN). You can enable the access point to dynamically receive an IP address from
your router’s DHCP server or you can specify a static IP address for your access point, as well as configure
DNS servers.
The access point’s default IP address is 192.168.1.230.
Select “DHCP Client” for your access point to be assigned a
dynamic IP address from your router’s DHCP server, or select
“Static IP” to manually specify a static/fixed IP address for
your access point (below).
Specify the IP address here. This IP address will be assigned
to your access point and will replace the default IP address.
