Technical data continued
Type AE101 AE301 AE501
Measuring frequency range
3rd-order changeover low-pass filter. Bes-
sel (-1 dB)
3rd-orderlow-passfilterBessel(-1 dB)
Hz
kHz
Hz
0 ... 10
0 ... 6
-
-
-
0 ... 10
3)
-
-
0 ... 10
Phase velocity
with 0...10 Hz filter
with 0...6 kHz filter
ms
µs
< 18
< 20
< 16
4)
-
< 17
-
Rise time with 0...10 Hz filter ms 25
5)
Overshoot in the case of voltage surge
with 0 ... 10 Hz filter
with 0 ... 6 kHz filter
%
%
0
<10
<2
-
Noise voltage
measuring range 0.2 mV/V (10 Hz)
measuring range 2 mV/V (10 Hz)
measuring range 1 mV/V (10 Hz)
measuring range 10 mV/V (10 Hz)
measuring range 8 mV/V (10 Hz)
measuring range 80 mV/V (10 Hz)
measuring range 0.2 mV/V (6 kHz)
measuring range 2 mV/V (6 kHz)
mV
rms
mV
rms
mV
rms
mV
rms
mV
rms
mV
rms
mV
rms
mV
rms
< 4
< 4
-
-
-
-
< 30
< 6
< 4
< 4
-
-
-
-
-
-
-
-
-
-
< 4
< 4
-
-
Long term drift over 48 hours (after 1 h
warm-up time)
µV/V
< 0.2
< 0.1
< 0.8
Effect of a 10 K-change in ambient tem-
perature
on sensitivity
% full
scale
< 0.1
typ 0.05
< 0.1
typ 0.05
< 0.1
typ 0.05
on zero point
measuring range 0.2 mV/V
measuring range 2 mV/V
meas. range 8 mV/V (1 mV/V)
meas. range 80 mV/V(10 mV/V)
mV
mV
mV
mV
< 60
< 10
-
-
< 10
< 4
-
-
-
-
<10
< 4
Effect of a +15 ... 30 V change in operat-
ing voltage
on sensitivity
zero point (350 Ω bridge resistance)
mV
mV
< 1
< 1
5V-synchronization (square wave) kHz - 76.8
Residual carrier voltage mV - < 5
Operating voltage (DC) V +15 ... 30
Power consumption mA ≤ 125 ≤ 100
Nominal temperature range °C -20 ... +60
Service temperature range °C -20 ... +60
Storage temperature range °C -25 ... +70
Degree of protection IP20
Weight g 200
3)
AE301S6: 0...2 (-1dB)
AE301S7: 0...60 (-1dB)
4)
AE301S6: <80 (filter frequency 2 Hz)
AE301S7: <2,8 (filter frequency 60 Hz)
5)
Rise time with AE301S7 6 ms
Rise time with AE301S6 200 ms
