38
PME-MP60/MP07
A0616-13.4 enHBM
Enter T10F characteristic values:
Group: TRANSDUCER
Unit: U/min
Input range: 1 MHz
F2 ON
Zero index (+) OFF
Frq x 4 ON
1)
Direction of rotation ON (only possible if F1 and F2 are active)
Switching threshold 2.5 V
Glitch filter ON
Zero kHz 0
Zero U/min 0
NVal kHz 144 kHz
NVal U/min 6000 U/min
Trans Err OFF
1)
every slope is counted, not just the pulses; this quadruples the resolution
NOTE
For frequency quadrupling, you have to adapt the input characteristics.
144 kHz (instead of 72 kHz with F2 = OFF) then correspond to a
revolution count of 6000 U/min.
Switch: F2 OFF ON OFF ON
Switch: Frq x 4 OFF OFF ON ON
Frequency display 1x 1x 2x 4x
Detection of direction
of rotation
no yes no yes
