Inputs /Outputs
Terminal plug 3: provided here for the control of PME functions are 4 inputs.
Terminal plug 4: Here you have 4 outputs available.
Group Parameters Meaning
IN/OUT Output
1)
1 - 4
Outputs 1 - 4 can be assigned the following functions for each
channel:
Limit value 1 to 4, standstill, error, inactive
Output1: F1, pulses; Output2: F2, direction of rotation
Mode
Off1...4
Output signal is inverted (Act. On) or not inverted (Act.Off).
The functions listed can be freely allocated to the remote
controls (I/Os).
Functions
Input level 0V Input level 24V
Taring Taring is started upon alternation from 0 V to 24 V.
Zero ba-
lance
Current measuring signal is set to zero upon alternation from
0 V to 24 V.
Shunt Shunt disconnected Shunt connected
PkMomMax ”Peak value” operating mode
for PkMax
”Current value” operating
mode for PkMax
PkMomMin ”Peak value” operating mode
for PkMin
”Current value” operating
mode for PkMin
PkHldMax Memory contents of PkMax
are updated
Memory contents of PkMax
are frozen
PkHldMin Memory contents of PkMin
are updated
Memory contents of PkMin
are frozen
ParaCo1 Selection of parameter sets and binary
coded inputs
ParaCo2
coded inputs
Parameter set ParaCo2 ParaCo1
1 0 0
2 0 1
3 1 0
4 1 1
