The first DAQ job with catman
EASY
CX22B / CX22B-W A3169-8.0 HBM: public 55
► Save your DAQ project: File menu −> Save −>
Project.
► Start your DAQ project via Start in the Measurement
group.
If you have not generated a visualization you will be
asked if one of the default settings for visualization
should be used.
► Click on Measure without display, if a monitor is not
connected during measurement.
CX22B‒W measurement mode is activated. If you have
defined a start trigger, e.g. The START/STOP button,
this will be waited for, if not, measurement will start. The
"RECORDING" LED flashes while waiting for the start
trigger and glows continuously as soon as measurement
starts.
Important
The "ERROR" LED lights up yellow if there is an error in
catman
EASY, e.g. if the connection to the devices at
project start cannot be set up or if the DAQ job cannot be
started. The "ERROR" LED flashes if the available free
memory drops below 1 GByte.
Tip
More information about catman
[
EASY can be found in
the catman
[
EASY online Help.
