HBM T40 - Page 26

26
T12
HBM
A24633.0en/de
Nominal (rated) torque M
nom
N⋅m 500
kN⋅m 1 2 3
Residual ripple
Voltage output mV t40
Effect of temperature per 10 K in the
nominal (rated) temperature range
on the output signal, related to the
actual value of the signal spread
Frequency output % "0.05
Voltage output % "0.2
on the zero signal, related to the
nominal (rated) sensitivity
Frequency output % "0.05
Voltage output % "0.1
Maximum level control range
4)
Frequency output kHz 2.5...17.5
1)
/ 15...105
2)
/ 60...420
3)
Voltage output V −12 ... +12
Power supply
Nominal (rated) supply voltage
(separated extralow DC voltage)
V 18 ... 30
Current consumption in measuring
mode
A < 1 (typ. 0.5)
Current consumption in startup mode A < 4 (typ. 2) 50 µs
Nominal (rated) power consumption W < 10
Maximum cable length m 50
Linearity error including hysteresis,
related to the nominal (rated) sensitivity
Frequency output % <"0.05
Voltage output % <"0.05
Relative standard deviation of
repeatability per DIN 1319, related to
the variation of the output signal
Frequency output % <"0.03
Voltage output % <"0.03
Shunt signal approx. 50% of M
nom
Tolerance of the shunt signal, related
to M
nom
% "0.03
Nominal (rated) trigger voltage V 5
Trigger voltage limit V 36
Shunt signal ON V min. > 2.5
Shunt signal OFF V max. < 0.7
1)
Option 5, 10"5 kHz (Code SU2)
2)
Option 5, 60"30 kHz (Code DU2)
3)
Option 5, 240"120 kHz (Code HU2)
4)
Output signal range in which there is a repeatable correlation between torque and output signal.
