HBM T40 - Page 27

27
T40
HBMA24633.0en/de
Nominal (rated) torque M
nom
N⋅m 500
kN⋅m 1 2 3
General data
EMC
Emission (per EN613261, Section 7)
RFI field strength − Class B
Interference immunity (per
EN613261, Table 2)
Electromagnetic field (AM) V/m 10
Magnetic field A/m 100
Electrostatic discharge (ESD)
Contact discharge kV 8
Air discharge kV 4
Rapid transients (burst) kV 1
Impulse voltages (surge) kV 1
Conducted interference (AM) V 10
Degree of protection per EN 60ā529 IP 54
Weight, approx. Rotor kg 2.0 4.0 4.1
Stator kg 1.1
Reference temperature °C [°F] 23 [ 73.4 ]
Nominal (rated) temperature range °C [°F] +10 ... +70 [ +50...+158 ]
Operating temperature range °C [°F] −20 ... +85 [ −4...+185 ]
Storage temperature range °C [°F] −40 ... +85 [ −40...+185 ]
Impact resistance, test severity level
per DINIEC68; Part 227;
IEC682271987
Number n 1000
Duration ms 3
Acceleration (half sine) m/s
2
650
Vibration resistance, test severity
level per DINIEC 68, Part 26:
IEC68261982
Frequency range Hz 5 ... 65
Duration h 1.5
Acceleration (amplitude) m/s
2
50
Nominal (rated) rational speed rpm 20,000 15,000
Load limits (data applies to the
nominal (rated) temperature range)
5
)
Limit torque, related to M
nom
% 200 160
Breaking torque, related to M
nom
% > 400 > 320
Longitudinal limit force kN 13 19 30 35
Lateral limit force kN 4 5 9 10
Bending limit moment N⋅m 200 220 560 600
Oscillation width per DIN 50100
(peaktopeak)
6)
N⋅m 1000 2000 4000 4800
5)
Each type of irregular stress (bending moment, lateral or longitudinal force, exceeding nominal (rated)
torque) can only be permitted up to its specified static load limit provided none of the others can occur at the
same time. If this condition is not met, the limit values must be reduced. If 30% of the bending limit moment
and lateral limit force occur at the same time, only 40% of the longitudinal limit force is permissible and the
nominal (rated) torque must not be exceeded. The permissible bending moments, longitudinal forces and
lateral forces can affect the measurement result by approx. 0.3% of the nominal (rated) torque. The load
limits apply only to the nominal temperature range. The load limits apply only to the nominal temperature
range. At temperatures t 10 C° load limits reduced by up to 30 % have to be allowed for because of
increasingly reduced viscosity at decreasing temperatures.
6)
The nominal (rated) torque must not be exceeded.
