CD 2301 Order No. BA 92-12-0231A Issue 05.01.10 41
8 Appendix
In the appendix, there is information of interest regarding technical data, spare part lists,
accessories, standards, etc.
8.1 Technical Data
Power Unit CD 2301 (with digital display)
for CD stud welding (capacitor discharge welding) according to current
standards
Welding range #4 to 5/16" (7/16" limited),
dia. 14 ga to 5/16" (dia. 3/8" limited);
(M3 to M8 (M10 limited),
dia. 2 to 8 mm (dia. 10 mm limited))
Welding material Mild steel, stainless steel, aluminum and
brass
Welding rate 8 to 20 studs/min
(depending on application and stud dia.)
Capacitance 99,000 μF
Welding time 1 to 3 msec
Energy 2,400 Ws
Charging voltage 50 to 220 V (stepless voltage regulation)
Primary power 115/230 V, 50/60 Hz, 10 AT
Power source Capacitor
Cooling type F (temperature controlled cooling fan)
Protection class IP 21 (not allowed to use while raining)
Operational and storage conditions According to current standards
Dimensions L x W x H 20.08" x 7.09" x 9.84" (510 x 180 x 250 mm)
without handle
Weight 46.30 lbs (21 kg)
