8.2 Spare Parts
Spare part list power unit type CD 2301 (92-12-0231A)
When ordering spare parts, please indicate order number and type of power unit.
Pos. Quantity Order-No. Description
5 1 88-11-890 Bottom plate
8 4 80-90-178 Screw M4 x 12
9 4 80-90-164 Washer 4 mm
10 4 80-10-203 Casing feet
13 3 80-11-359 Conductor mark
20 1 80-30-368A Capacitor battery
21 4 80-90-128 Spring washer 5 mm
22 4 80-90-250 Screw M5 x 8
25 1 88-11-785A Rear wall complete
26 16 80-90-158 Screw M4 x 6 black
27 4 80-90-184 Tooth lock washer A4
30 1 80-50-565 Mains cable
35 1 88-11-781B Front plate
36 1 80-90-253 Screw M8 x 25
37 2 80-90-150 Washer 8 mm
38 2 80-90-167 Cupal washer M 8
39 1 80-90-140 Spring washer 8 mm
40 1 80-90-141 Nut M8
42 1 80-70-296 Connection cable
43 1 80-70-293 Connection cable
50 1 88-11-891 Cover
51 1 80-11-847 Label matt black
55 1 80-10-857 Handle A=300
56 2 80-90-199 Screw M5 x 12
57 2 80-90-185 Washer 5 mm
58 2 80-90-225 Head nut M5
65 1 80-11-848 Label matt white
70 1 80-11-754 HBS-Logo small, 37 x 28
1 80-70-294 Harness
