48 CD 2301 Order No. BA 92-12-0231A Issue 05.01.10
Spare part list front plate complete (88-11-781B)
Pos. Quantity Order No. Description
5 1 88-11-782 Front plate
10 1 88-11-270 Board support
11 2 80-90-121 Spring washer 4 mm
12 2 80-90-153 Nut M 4
25 2 80-50-035 Mounting sleeve
26 2 80-10-576 Flat connection
27 2 80-56-215 Capacitor noise suppression
29 2 80-90-137 Screw M3 x 8
30 1 80-30-300 Control cable sleeve
32 1 80-50-047 Fuse element
33 1 80-50-028 Fine-wire fuse 10 AT
35 1 80-50-050 Mains switch
36 1 80-10-837 Dust protection cap
40 2 88-11-784 Distance sleeve 8 x 13
45 1 80-80-502V3.1 Electronic board CD processor V3.1
50 2 80-10-046 Distance stud
55 1 80-80-5034 Electronic board CD supply
56 1 88-11-653 Connection cable
60 2 80-90-249 Screw M3 x 6
65 1 88-11-694B Front film
80 1 80-11-359 Conductor mark
8 Appendix
8.2 Spare Parts
