50 CD 2301 Order No. BA 92-12-0231A Issue 05.01.10
Spare part list rear wall complete (88-11-785A)
Pos. Quantity Order No. Description
5 1 88-17-995 Rear wall
10 1 80-50-049 Fan
13 4 80-90-252 Blind rivet 4 x 16, aluminum
14 1 80-90-184 Tooth lock washer A4
15 1 80-11-440 Screwed cable connection
20 1 80-11-441 Lock nut
24 2 80-90-194 Tooth lock washer A3
25 1 80-50-775 Mains interference filter
27 2 80-90-131 Washer 3 mm
28 2 80-90-190 Spring washer 3 mm
29 2 80-90-165 Nut M 3
31 1 80-11-356 Conductor mark L1
32 1 80-11-357 Conductor mark N
33 1 80-11-358 Conductor mark PE
34 1 80-11-359 Conductor mark SC
37 1 80-90-177 Tooth lock washer A 5
38 2 80-90-188 Nut M 5
39 2 80-90-202 Washer 5 mm
41 1 80-90-128 Spring washer 5 mm
8 Appendix
8.2 Spare Parts
