CONTROLS AND INSTRUMENTS
STEERING WHEEL
Turns the front wheels
MAIN SWITCH (fig. 22A)
This switch has three positions:
STOP,
ON,
START - engine starter
After starting the engine and releasing the switch in the START position, the switch will
automatically return to the ON position.
THROTTLE (fig. 23A)
Regulates engine speed.
The dashboard shows the following positions:
b CHOKE Choke
d SLOW the lowest engine speed
c FAST the highest engine speed
• In the CHOKE position the mixture is enriched, so this position can be used only for the time
required during a cold start and engine warm-up.
• To move without mowing, place the lever in the position between SLOW and FAST.
• During mowing, move the lever to the FAST position.
BLADE ROTATION SWITCH (fig. 24A)
- starts or stops the rotation of the blades. The blades are engaged when the switch is
put in the "ON" position
Blades released Blades in engagement
- it also serves as an emergency switch. Quickly disengaging this switch will turn
the mower off in the event of an emergency.
FRONT LIGHT SWITCH (fig. 23b)
The light switches on with the switch on the dashboard.
It can only be switched on when the ignition main switch is in the ON position.
CUTTING HEIGHT ADJUSTMENT LEVER (fig. 25A)
To readjust the cutting height, it is first necessary to push the lever to the side (away from
yourself), move it forwards or backwards to the desired position, release the push and slide
the lever into one of the grooves.
BRAKE/CLUTCH PEDAL (fig. 26A)
This pedal has a dual function BRAKE / CLUTCH
