12 Rope guide
12.1 Function
The rope leads the sheet on its way from the pile to
the forwarding roller. Tension springs maintain a
constant rope tension that is independent of the
sheet size adjustment.
12.2 Replacing the rope
Warning – risk of injury
Press the emergency stop button on
the feeder before you start replacing
the rope. Secure the feeder against
being switched back on. - One end of
the rope is connected with a spring.
The spring ensures a constant rope
tension. Removing: Slacken an intact
rope before you remove it. Installation:
Fasten the spring before you tighten
the rope at the suction head.
If the rope breaks, you must install a new rope in the
rope guide.
Note
The structure of the rope guide on O.S.
is mirrored to the structure of the rope
guide on D.S. We recommend to start
with removing the rope at one side only.
When mounting the new rope, you can
use the intact rope guide to orientate
yourself.
Tip
Move the suction head to the rearmost
position (largest format). This gives
you sufficient space for the rope
change.
