Selecting a pocket table in Programming mode
Proceed as follows to select the pocket table in the Programming
mode of operation:
To call the file manager, press the PGM MGT key.
Press the SHOW ALL soft key
Select a file or enter a new file name
Confirm your entry with the ENT key or the
SELECT soft key
Abbr. Inputs Dialog
P
Pocket number of the tool in the tool magazine -
T
Tool number
Tool number?
RSV
Pocket reservation for box magazines
Pocket reserv.: Yes =
ENT / No = NOENT
ST
Special tool (ST); If your special tool blocks pockets in front of
and behind its actual pocket, these additional pockets need to
be locked in column L (status L).
Special tool?
F
The tool is always returned to the same pocket in the tool
magazine
Fixed pocket? Yes =
ENT / No = NO ENT
L
Locked pocket (L: for Locked)
Pocket locked Yes =
ENT / No = NO ENT
DOC
Display of the comment to the tool from TOOL.T -
PLC
Information on this tool pocket that is to be sent to the PLC
PLC status?
P1 ... P5
Function is defined by the machine tool builder. The machine
tool documentation provides further information
Value?
PTYP
Tool type. Function is defined by the machine tool builder. The
machine tool documentation provides further information
Tool type for pocket
table?
LOCKED_ABOVE
Box magazine: Lock the pocket above
Lock the pocket
above?
LOCKED_BELOW
Box magazine: Lock the pocket below
Lock the pocket
below?
LOCKED_LEFT
Box magazine: Lock the pocket at left
Lock the pocket at
left?
LOCKED_RIGHT
Box magazine: Lock the pocket at right
Lock the pocket at
right?
