Tools | Tool management (option number 93)

266

HEIDENHAIN | TNC 620 | Conversational Programming User's Manual | 10/2017

Available tool types

The tool management displays the various tool types with an icon. The following tool types are available:

Icon Tool type Tool type number

Undefined,****

Milling cutter,MILL

Drill,DRILL

Tap,TAP

Center drill,CENT

Turning Tool,TURN

Touch probe,TCHP

Ream,REAM

Countersink,CSINK

Piloted counterbore(TSINK),TSINK

Boring tool,BOR

Back boring tool,BCKBOR

Thread mill,GF

Thread mill w/ countersink,GSF

Thread mill w/ single thread,EP

Thread mill w/ indxbl insert,WSP

Thread milling drill,BGF

Circular thread mill,ZBGF
