Tools | Tool management (option number 93)

HEIDENHAIN | TNC 620 | Conversational Programming User's Manual | 10/2017

267

Icon Tool type Tool type number

Roughing cutter (MILL_R),MILL_R

Finishing cutter (MILL_F),MILL_F

Rough/finish cutter,MILL_RF

Floor finisher(MILL_FD),MILL_FD

Side finisher (MILL_FS),MILL_FS

Face milling cutter,MILL_FACE
