Programming Contours | Path contours  Cartesian coordinates

HEIDENHAIN | TNC 620 | Conversational Programming User's Manual | 10/2017

295

Example

10 L X+40 Y+40 RL F200 M3

11 CR X+70 Y+40 R+20 DR- (arc 1)

11 CR X+70 Y+40 R+20 DR+ (arc 2)

11 CR X+70 Y+40 R-20 DR- (arc 3)

11 CR X+70 Y+40 R-20 DR+ (arc 4)
