Programming Contours | Path contours – FK free contour programming (option 19)

322

HEIDENHAIN | TNC 620 | Conversational Programming User's Manual | 10/2017

30 DEP CT CCA90 R+5 F1000

Depart the contour on a circular arc with tangential

connection

31 L X-70 R0 FMAX

32 L Z+250 R0 FMAX M2

Retract the tool, end program
