Programming Q Parameters | Additional functions

384

HEIDENHAIN | TNC 620 | Conversational Programming User's Manual | 10/2017

Error number Text

1094 Tool name not permitted

1095 Software option not active

1096 Kinematics cannot be restored

1097 Function not permitted

1098 Contradictory workpc. blank dim.

1099 Measuring position not allowed

1100 Kinematic access not possible

1101 Meas. pos. not in traverse range

1102 Preset compensation not possible

1103 Tool radius too large

1104 Plunging type is not possible

1105 Plunge angle incorrectly defined

1106 Angular length is undefined

1107 Slot width is too large

1108 Scaling factors not equal

1109 Tool data inconsistent
