Programming Q Parameters | Additional functions

414

HEIDENHAIN | TNC 620 | Conversational Programming User's Manual | 10/2017

Group

name

Gruppen-

nummerID

Systemdaten-

nummer

Index Description

11 - Z component of the X direction

12 - Type of angle definition:

13 - Angle 1

14 - Angle 2

15 - Angle 3
