Programming Q Parameters | Additional functions

420

HEIDENHAIN | TNC 620 | Conversational Programming User's Manual | 10/2017

Group

name

Gruppen-

nummerID

Systemdaten-

nummer

Index Description

Read and write data of touch probes (TS, TT) (system string)

10350 74 - Serial number of the active tool touch probe

TT from CfgProbes/activeTT.

Read the data for pallet processing (system string)

1 - Pallet name.10510

2 - Path of the selected pallet table.

Read version ID of the NC software (system string)

10630 10 - This string corresponds to the format of

the version ID displayed, i.e. 340590 07 or

817601 04 SP1.

Read data of the current tool (system string)

10950 1 - Current tool name.

Example: Assign the value of the active scaling factor for the Z

axis to Q25.

55 FN 18: SYSREAD Q25 = ID210 NR4 IDX3
