Testing the EPC9 EPC9 Manual 28
The following figure shows a recorded action potential (from H. Taschenberger & H.
von Germsdorff):
normal current clamp
250 µs
20 mV
0 mV
-60 mV
Presynaptic Action Potential
of the Calyx of Held
in the Rat Brainstem
fast current clamp
