Ch. 17 REAR BRAKE / WHEEL / SUSPENSION
17-14
Removal 4 bolts which fix the stabilizer bar.
Installation
Install the stabilizer bar and tighten the bolts.
Torque: 2.8 kg-m
Removal 4 bolts fix the rear brake disk.
Installation
Install the rear brake disk and tighten the bolts.
Torque: 2.5 kg-m
Removal the rear differential 3 bolts.
Installation
Install the rear differential and tighten the bolts.
Torque: 4.5 kg-m
