Description
034-11592_1.0_19.11.2018
30
Dampers which dampen rebound deflection
movements, i.e. a rebound load, are called rebound
dampers or dashpots.
3.3.3 Suspension fork structure
1
1
2
3
4
5
6
7
8
7
Figure 6: Example: Suntour fork – The stem and handlebars are fastened to
the fork shaft (1). The wheel is fastened to the quick release axle
(5). Other elements: The compression setting (2), crown (3), Q-Loc
(4), fork end for quick release (6), stanchion (7) and spring (8)
