Before the first ride
034-11592_1.0_19.11.2018
74
Figure 36: Optimal saddle height
6.1.3 Adjusting the seat height with quick release
3
4
5
1
2
3
 Open the quick release on the seat post to change
the seat height. To do so, pull the clamping lever
away from the seat post.
Figure 37: Seat post quick release (3) with clamping lever (5) and setting
bolt (4) in the open position (1) and in the direction of the closed
position (2)
