Description
3.5.3.1 USB port
Test instruments can be connected to the USB
diagnostics port to check the drive system. The USB
diagnostics port does not have any other functions.
3.5.3.2 Displays
The control panel with display has seven screen
displays:
1
4
5
6
2
2
3
7
Figure 17: Overview of the displays
Table 11: Overview of the screen display
1 Unit of measure for speed
2 Tachometer screen
3 Function screen
4 Driving light symbol
5 Service symbol
6 Charge status indicator
7 Level of assistance
Use
