Description
034-11421_0.1_10.10.2017
24
4 Description
4.1 Overview
Figure 2: Bicycle, viewed from the right, example of Pasero
1 Front wheel
2 Fork
3 Front mudguard
4 Lamp
5 Handlebars
6 Stem
7Frame
8 Seat post
9 Saddle
10 Pannier rack
11 Rear light and reflector
12 Rear mudguard
13 Kickstand
14 Chain
15 Rear wheel
16 Chain guard
17 Battery
18 Frame number and type plate
1
2
3
4
5
6
7
8
9
10
11
12
13 14 15 16 17
18
EN_034-11421_0.1_0.01_09.18_HERCULES BROSE_CS_Inhalt.book Page 24 Wednesday, October 11, 2017 9:53 AM
