4.6.3.2 Displays
The display has 10 different displays:
Figure 13: Overview of the displays
1
10
2
3
4
567
9
8
Use
1 Function display
2 Level of assistance
3 Unit of measure for speed
4 Display of rider's power output
5 Warning symbol
6 Running light symbol
7 Pushing aid symbol
8 Battery status indicator
9 Display of motor's power output
10 Current speed
Table 20: Overview of the screen display
