Description
4.2 Handlebars
Figure 3: Detailed view of bicycle from rider position, example
1 Rear brake lever
2Bell
3 Lamp
4 Front brake lever
5 Front derailleur shifter
6 Command console
7Display
8 Fork lock on suspension fork head
9 Rear derailleur shifter
21
1
2
3
4
6
5
7
8
9
