Operation
034-11421_0.1_10.10.2017
66
7.4.1.2 Inserting the integrated battery
 Place the battery in the bottom mount with the
contacts first.
 Flip the integrated battery up so that it is held by the
retainer guard.
 Push the integrated battery upwards so that it
audibly clicks into place.
 Check the inserted battery to make sure it is firmly
in place.
 Lock the battery with the key. Otherwise the battery
may fall out of the mount when you open the lock.
 Remove the key from the lock.
7.4.2 Down tube battery

Before the battery is to be removed or inserted, switch
off the battery and the drive system.
7.4.2.1 Removing the down tube battery
 Open the battery lock with the key.
 Remove the key from the lock.
 Tip the down tube battery out of the top mount.
 Pull the down tube battery out of the top mount.
