Hercules PASERO - Setting the Grip Distance of the Brake Lever; Figure 20: Brake Lever (1) with Knurled Screw (2)

034-11421_0.1_10.10.2017
55
Adjusting the bicycle to the rider
 For fine setting, adjust the filling pressure using the
fork valve.
 Screw the screw cover back on.
6.4 Setting the grip distance of the brake lever
 Set the grip distance using the knurled screw on the
brake lever.
 The rider can use the brake lever comfortably.
Figure 20: Brake lever (1) with knurled screw (2)
2
1
2
