Hercules PASERO - Figure 10: Details of the down Tube Battery from the Right (I) and Left (II); Figure 11: Seat Tube Battery Details

034-11421_1.0_11.10.2017
33
Description
Figure 10: Details of the down tube battery from the right (I) and left (II)
1 Port for charger plug
2Battery lock
3 Handle
4 Operating and charge status indicator with
On-Off button (battery)
Figure 11: Seat tube battery details
1 Handle
2Battery lock
3 Operating and charge status indicator with
On-Off button (battery)
4 Port for charger plug
1
2
3
4
III
1
2
3
4
